COURSE DESCRIPTION:
Power conditioning is the enabling technology necessary for interfacing various distributed generator (DG) systems to electric utility and to power stand-alone loads. Power semiconductor devices are examined from an application perspective. After examining the basic conversion blocks, the course delves into suitable power conversion architectures (topologies). Examples include: (a) Fuel Cell power conversion system with battery/super-capacitor type energy storage for powering stand-alone residential loads with an option to interface to electric utility; (b) Power conversion architectures for a high speed gas turbine (microturbine) type DG; (c) Suitable converters for fuel cell turbine hybrid will also be considered.
Power electronics is an enabling technology for almost all electrical applications. The field is growing rapidly because electrical devices need electronic circuits to process their energy. Elements of Power Electronics, the first book to discuss this subject in a conceptual framework, provides comprehensive coverage of power electronics at a level suitable for novices in the field. It aims to establish a fundamental engineering basis for power electronics analysis, design, and implementation. More than 160 examples and 350 chapter problems support the presented concepts.
PREREQUISITES:
Fundamental courses in power systems and electronic circuits.
BENEFITS:
Completion of this course will provide participants with both a review of and discussion of the specific design issues most likely to be encountered in designing Power Conditioning systems for fuel cell, microturbine, and hybrid Distributed Generation power plants. Understanding these issues will allow the participants to properly address them with the most appropriate cost-effective technical solutions.
INTENDED AUDIENCE:
Those individuals that have a previously developed understanding of the fundamentals of Power Conditioning and want to learn how to apply that basic knowledge to the design of specific Distributed Generation system applications including fuel cells, microturbines, and hybrid systems containing both fuel cells and microturbines, for both stand-alone and utility-grid connected situations.
OUTLINE:
To study in-depth fundamentals of modern power conditioning approaches (topologies) suitable for fuel cell powered systems, for stand-alone and/or utility interface.
Unit 1: Introduction to Fuel Cell Power Conditioning
- System configurations
o Fuel cell power source for standalone system applications
o Fuel cell power source for utility intertie applications
o Microturbine or gas turbine power source system configuration
o Hybrid fuel cell with microturbine system configuration
- Example systems and their features
o Individual components in the example systems
o Specifications
- Overview of power converters and two-day course contents
Unit 2: Multiple-Switches DC-DC Converters with Isolation
- Half-Bridge Converter
o PWM and converter operating modes
o Discussion of voltage and current waveforms
- Push-Pull Bridge Converter
o PWM and converter operating modes
o Discussion of voltage and current waveforms
- Full Bridge Converter
o PWM and output voltage relationship
o Discussion of voltage and current waveforms with PWM
o Phase-shift-modulation (PSM) Method
o Discussion of voltage and current waveform with PSM
Unit 3: Isolated DC-DC Converter Controller Design Example
- Full-bridge (or Flyback) Converter Design Example
o Power stage design with device and component selection
o Construction of open-loop transfer function
- Current- and Voltage-Loop Controllers Design
o Compensator design
o Bode plots for stability test
o Closed-loop responses
- Realization of Compensator Circuit
o PI compensator realization with op amp circuits
o PID compensator realization with op amp circuits
- Commercial-IC Controllers
o Complete circuit diagram for the design example
o Simulation (and/or) experimental results
Unit 4: Design of Single-Phase DC-AC Inverters
- Power Stage Design
o DC bus voltage requirement
o Power device ratings
o DC bus capacitor requirement
o Power bus bar requirement
o Design example
- PWM Switching Design
o Complementary PWM technique in full-bridge inverter
o Dead time requirement
o Short-pulse elimination requirement
o Design example
- Output Filter Design
o Sizing ac filter inductor and capacitor
o Design example
Unit 5: Fuel-Cell Powered System with Single-Phase AC Output Loads
- System Architectures
o Isolation requirement and options
o Low-voltage energy storage design method
o High-voltage energy storage design method
- Critical Evaluation of DC-DC converter options
o Device voltage and current requirements
o Matrix comparison of dc-dc converters for fuel cell source
- Critical Evaluation of DC-AC converter options
o Device voltage and current requirement
o Matrix comparison of dc-ac inverters for single-phase outputs
Unit 6: Design of a 10-kW Design Example with 48-V DC Input and 120/240 V AC Output
- Inverter Circuit Topologies Dealing with Unbalanced Loads
o Two full-bridge inverters
o Two half-bridge inverters
o Three-leg inverter
- Power stage design
o Power device voltage and current ratings
o Passive component voltage and current ratings
- Sensor and Sensor Conditioning
o Voltage and current sensors
o Temperature sensors
o Signal conditioning and scaling
- Controller Implementation
o Analog implementation
o Digital signal processor (DSP) and Interface
o Communication with fuel cell controller
Unit 7: Microturbine Power Conversion Systems
- System Architecture of microturbine
o Block diagrams of microturbine systems
o Electronic actuator and hydraulic controllers
o Three-phase or multi-phase permanent magnet (PM) generators
o Three-phase ac output with and without power electronics
- Generator Output AC-DC Stage Rectification
o Three-phase diode rectifier for ac-dc rectification
o Three-phase active-front-end rectification
- DC-AC Inverter for Standalone and Utility Interconnects
o Three-phase diode rectifier for ac-dc rectification
o Three-phase active-front-end rectifier
Fasilitas Yang Diperoleh
- Lokasi Training di Hotel Bintang 3-5
- Ruang Pelatihan Full AC, Toilet dan Musholla
- Perlengkapan Visual LCD Proyektor, & Whiteboard
- Modul / Handout(Hard Copy & Soft Copy)
- Training Kit (Co-Card, Bolpoin, & Buku Catatan)
- 1x Makan Siang dan 2x Coffee Break (Snack)
- Penjemputan Bandara Hotel (Pulang-Pergi selama pelatihan)
- Basement Tempat Parkir Motor dan Mobil yang Aman
- Akses Internet Wireless
- Smoking Area.
- Sertifikat Keikutsertaan Training
- Merchandise menarik dari Duta Pro Training & Consulting
- Konsultasi dengan Instruktur/Narasumber setelah Pelatihan
Biaya Training
- Rp 6.800.000,- / Peserta (termasuk penginapan, minimal 2 peserta)
